You are here: Home / Products / Professional Speaker / Line Array / VT-36 & VT33 Dual 10" three way line array speaker set
Share to:

VT-36 & VT33 Dual 10" three way line array speaker set

Compact, high performance three-way line array speaker
High-power system with 10in neodymium LF, 8in neodymium MF
and 3in HF neodymium drivers.
Sanding texture paint for touring jobs

Quantity:
  • VT-36 &VT-33
  • BOWAY
  • 85182200

Description


Feature

Compact, high performance three-way line array speaker

High-power system with 10in neodymium LF, 8in neodymium MF

and 3in HF neodymium drivers.
Sanding texture paint for touring jobs



Applications

Touring sound reinforcement
Stadiums, arenas, concert halls and theaters
Medium/large-scale events



Specifications


Type

Compact three-way line array speaker

Model name

VT-36

Frequency Response

70Hz-18KHz

Drivers

two 10” LF Woofers, two 8” MF woofer   and two 3” HF driver, all neodymium

Rated Power

HF/MF/LF 120W/130W/800W(RMS),

Sensitivity

HF/MF 115dB, LF 100dB@ 1m/1w

Maximum SPL

HF/MF/LF 136dB/ 136dB / 144dB

Nominal Impedance

HF/MF/LF 16/8/8Ω

Finish

Sanding texture paint

Protective Grille

Black perforated steel

Connectors

2×Neutrik NL4

Fittings

Proprietary rigging system

Dimensions(mm)

(W)700mmx(H)310mmx(D)580mm

Weight

40.5KG




Type

18” +15” horn loaded rigging subwoofer

Model name

VT-33

Frequency Response

18” 27Hz-200Hz, 15” 35Hz-200Hz

Drivers

One 15” bass driver and one 18” bass   driver, all neodymium

Rated Power

18” 800W(RMS), 15” 600W(RMS)

Sensitivity

108dB @ 1m/1w

Maximum SPL

137dB peak

Nominal Impedance

Finish

Sanding texture paint

Protective Grille

Black perforated steel

Connectors

2×Neutrik NL4

Fittings

Proprietary rigging system

Dimensions(mm)

(W)700mmx(H)600mmx(D)800mm

Weight

68KG




未标题-1

Q: How Maker hart quote?
A: We will provide FOB price and all based on minimum order quantity (MOQ).


Q: How can I get your quotation?
A: Please provide us information as below:
1. Item Number.
2. Quantity.
3. Company Profile (Name, Tel, Fax, Address, and Webpage)
4. Any Other Relevant Details.


Q: How long is the lead time after placing the order?
A: Lead time depends on a number of factors, such as the stock and production status. Usually the sample orders take about AROUND 1 WEEK, and the mass orders take AROUND THREE WEEKS after the order is placed.


Q: How long does the delivery time take?
A: We send our goods from JIANGMEN, Guangdong, and the delivery time depends on the location of your delivery address, and the shipping way will be Express Service, Sea Shipping, Air Shipping for you reference.


Q: What's your standard package?
A:Carton packaging outside, and also can be with flight case if you need.


Q: Could you do OEM/ODM for customers?
A: Yes, from the product design to packaging, our engineers can design exactly as your requirements. Any kind of logo printing or design is available if your order quantity is good .
