The DW-S9000 is a two-channel Class D power amplifier delivering 2 × 4,500 W into 8 Ω, or 13,500 W bridged, from a 1.5U chassis weighing 14 kg. It is the channel-count that matters here: two channels, each with the current capability to drive a large flown array hang or a bank of high-power subwoofers, rather than four channels sharing one supply.
| Quantity: | |
|---|---|
DW-S9000
D&L
Key Features
» | 2 × 4,500 W into 8 Ω, 2 × 6,750 W into 4 Ω, 2 × 10,125 W into 2 Ω from a 1.5U, 14 kg chassis |
» | Bridged mode: 1 × 13,500 W into 8 Ω, 1 × 20,250 W into 4 Ω |
» | Silicon carbide output devices – junction rating around 200 °C against roughly 150 °C for conventional silicon |
» | Damping factor > 5,000, equivalent to an output impedance of about 0.0016 Ω |
» | Active PFC across the full mains range – stable output on shared distro and unstable local supply |
» | Four variable-speed axial fans in twin banks either side of the central heatsink, front-to-rear airflow |
» | Cast aluminium side cheeks with fin-cut channels serving as both handles and passive heatsinks |
» | Metal level controls with illuminated status rings, readable in low stage light |
» | Front-panel display: real-time per-channel temperature and bar-graph signal level, with touch lockout |
» | Recessed hex-head external fasteners with anti-oxidation plating |
» | Full protection suite: short circuit, thermal, DC offset, soft start, clip and long-term power limiting |
